| Mã đặt hàng | Model | Lớp mạ | iC | l | r | s |
| mm | mm | mm | mm | |||
| 302100.0150 | SNMG090304-PM | 4215 | 9.52 | 9 | 0.4 | 3.18 |
| 302100.0251 | SNMG090304-PM | 4325 | 9.52 | 9 | 0.4 | 3.18 |
| 302100.0350 | SNMG090308-PM | 4215 | 9.52 | 9 | 0.8 | 3.18 |
| 302100.0451 | SNMG090308-PM | 4325 | 9.52 | 9 | 0.8 | 3.18 |
| 302100.0460 | SNMG090308-MF | 235 | 9.52 | 9 | 0.8 | 3.18 |
| 302100.0500 | SNMG120404-MF | 2015 | 12.7 | 12 | 0.4 | 4.76 |
| 302100.0650 | SNMG120404-PM | 4215 | 12.7 | 12 | 0.4 | 4.76 |
| 302100.0751 | SNMG120404-PM | 4325 | 12.7 | 12 | 0.4 | 4.76 |
| 302100.0800 | SNMG120408-MF | 2015 | 12.7 | 12 | 0.8 | 4.76 |
| 302100.0900 | SNMG120408-MR | 2025 | 12.7 | 12 | 0.8 | 4.76 |
| 302100.1000 | SNMG120408-MR | 2035 | 12.7 | 12 | 0.8 | 4.76 |
| 302100.1150 | SNMG120408-PF | 4215 | 12.7 | 12 | 0.8 | 4.76 |
| 302100.1250 | SNMG120408-PM | 4215 | 12.7 | 12 | 0.8 | 4.76 |
| 302100.1351 | SNMG120408-PM | 4325 | 12.7 | 12 | 0.8 | 4.76 |
| 302100.1450 | SNMG120408-PM | 4235 | 12.7 | 12 | 0.8 | 4.76 |
| 302100.1551 | SNMG120408-PR | 4325 | 12.7 | 12 | 0.8 | 4.76 |
| 302100.1650 | SNMG120408-PR | 4235 | 12.7 | 12 | 0.8 | 4.76 |
| 302100.1700 | SNMG120408-MM | 2015 | 12.7 | 12 | 0.8 | 4.76 |
| 302100.1800 | SNMG120408-MM | 2025 | 12.7 | 12 | 0.8 | 4.76 |
| 302100.1900 | SNMG120412-MR | 2035 | 12.7 | 12 | 1.2 | 4.76 |
| 302100.2050 | SNMG120412-PM | 4215 | 12.7 | 12 | 1.2 | 4.76 |
| 302100.2151 | SNMG120412-PM | 4325 | 12.7 | 12 | 1.2 | 4.76 |
| 302100.2250 | SNMG120412-PR | 4235 | 12.7 | 12 | 1.2 | 4.76 |
| 302100.2300 | SNMG120412-MM | 2025 | 12.7 | 12 | 1.2 | 4.76 |
302100 - Indexable insert SNMG T-MAX P
P M K
Double-sided, square.
Geometries
• P (steel), M (stainless), K (cast iron), N (non-ferrous metals), S (superalloys), H (hard)
• F (fiish machining), M (intermediate machining), R (rough machining)
Types
• 2015: fiish machining and light rough machining of stainless steel
• 2025: pre-fiishing/rough machining of stainless steel
• 2035: pre-fiishing/rough machining of stainless steel
• 4215: fiishing/rough machining of steel/cast steel
• 4225: fiishing/rough machining of steel/cast steel
• 4235: rough machining of steel/cast steel
| Mã đặt hàng | Model | Lớp mạ | iC | l | r | s |
| mm | mm | mm | mm | |||
| 302100.0150 | SNMG090304-PM | 4215 | 9.52 | 9 | 0.4 | 3.18 |
| 302100.0251 | SNMG090304-PM | 4325 | 9.52 | 9 | 0.4 | 3.18 |
| 302100.0350 | SNMG090308-PM | 4215 | 9.52 | 9 | 0.8 | 3.18 |
| 302100.0451 | SNMG090308-PM | 4325 | 9.52 | 9 | 0.8 | 3.18 |
| 302100.0460 | SNMG090308-MF | 235 | 9.52 | 9 | 0.8 | 3.18 |
| 302100.0500 | SNMG120404-MF | 2015 | 12.7 | 12 | 0.4 | 4.76 |
| 302100.0650 | SNMG120404-PM | 4215 | 12.7 | 12 | 0.4 | 4.76 |
| 302100.0751 | SNMG120404-PM | 4325 | 12.7 | 12 | 0.4 | 4.76 |
| 302100.0800 | SNMG120408-MF | 2015 | 12.7 | 12 | 0.8 | 4.76 |
| 302100.0900 | SNMG120408-MR | 2025 | 12.7 | 12 | 0.8 | 4.76 |
| 302100.1000 | SNMG120408-MR | 2035 | 12.7 | 12 | 0.8 | 4.76 |
| 302100.1150 | SNMG120408-PF | 4215 | 12.7 | 12 | 0.8 | 4.76 |
| 302100.1250 | SNMG120408-PM | 4215 | 12.7 | 12 | 0.8 | 4.76 |
| 302100.1351 | SNMG120408-PM | 4325 | 12.7 | 12 | 0.8 | 4.76 |
| 302100.1450 | SNMG120408-PM | 4235 | 12.7 | 12 | 0.8 | 4.76 |
| 302100.1551 | SNMG120408-PR | 4325 | 12.7 | 12 | 0.8 | 4.76 |
| 302100.1650 | SNMG120408-PR | 4235 | 12.7 | 12 | 0.8 | 4.76 |
| 302100.1700 | SNMG120408-MM | 2015 | 12.7 | 12 | 0.8 | 4.76 |
| 302100.1800 | SNMG120408-MM | 2025 | 12.7 | 12 | 0.8 | 4.76 |
| 302100.1900 | SNMG120412-MR | 2035 | 12.7 | 12 | 1.2 | 4.76 |
| 302100.2050 | SNMG120412-PM | 4215 | 12.7 | 12 | 1.2 | 4.76 |
| 302100.2151 | SNMG120412-PM | 4325 | 12.7 | 12 | 1.2 | 4.76 |
| 302100.2250 | SNMG120412-PR | 4235 | 12.7 | 12 | 1.2 | 4.76 |
| 302100.2300 | SNMG120412-MM | 2025 | 12.7 | 12 | 1.2 | 4.76 |
302100 - Indexable insert SNMG T-MAX P
P M K
Double-sided, square.
Geometries
• P (steel), M (stainless), K (cast iron), N (non-ferrous metals), S (superalloys), H (hard)
• F (fiish machining), M (intermediate machining), R (rough machining)
Types
• 2015: fiish machining and light rough machining of stainless steel
• 2025: pre-fiishing/rough machining of stainless steel
• 2035: pre-fiishing/rough machining of stainless steel
• 4215: fiishing/rough machining of steel/cast steel
• 4225: fiishing/rough machining of steel/cast steel
• 4235: rough machining of steel/cast steel
