| Mã đặt hàng | Kiểu | Dải đo | Độ phân giải | Áp lực đo | Độ chính xác | Tiêu chuẩn chống nước | Chiều cao số |
| mm | nn | N | µm |
||||
| 123610.0100 | 9 | 2000 ±0. | 0.0002 | 0.7...0.9 | 0.6±1Digit | IP54 | 6.5 |
| 123610.0200 | 2001 | ±0.9 | 0.0002 | 0.7...0.9 | 0.6±1Digit | IP54 | 6.5 |
123610 - Precision gauge digital MAHR Millimess
High-contrast LCD display with additional analog display. Suitable for roundness and fltness inspections and for fiding the reversal point when measuring bore holes.
Features:
LCD display
RESET (setting displays to zero)
PRESET (fied value setting)
Conversion mm/inch
Reversible count direction
RANGE (selection of scale range)
ABS (reference to point of origin)
Display rotatable 280°
Data output MarConnect
Additional functions Type 2001:
MIN / MAX storage of reversal point search data
MAX-MIN for run-out/fltness inspection
TOL tolerance input
Control output
Package contents:
Delivered in transport packaging incl. rubber bellows, mains power adapter and key for forward
stroke adjustment.
Appropriate accessories:
Signal lines 109275 /.0210 /.0310 /.2120
Measuring inserts 124008; 124010
