| Mã đặt hàng | Cone | d1 | A | d2 | l1 | l5 |
| mm | mm | mm | mm | mm | ||
| 332000.0200 | BT40 | 16 | 55 | 32 | 27 | 17 |
| 332000.0300 | BT40 | 22 | 55 | 40 | 31 | 19 |
| 332000.0400 | BT40 | 27 | 55 | 48 | 33 | 21 |
| 332000.0500 | BT40 | 32 | 60 | 58 | 38 | 24 |
| 332000.0600 | BT40 | 40 | 60 | 70 | 41 | 27 |
332000 Toolholder DIEBOLD
MAS BT, form A, balanced for 8000 rpm
DIN 6358, short version.
Application: For shell end mill and cutting insert mill cutter.
Appropriate accessories:
339610 Cutter spindle key
339720 Cone cleaner
Scope of delivery: With taper key, cutter tightening screw and lathe dog ring
| Mã đặt hàng | Cone | d1 | A | d2 | l1 | l5 |
| mm | mm | mm | mm | mm | ||
| 332000.0200 | BT40 | 16 | 55 | 32 | 27 | 17 |
| 332000.0300 | BT40 | 22 | 55 | 40 | 31 | 19 |
| 332000.0400 | BT40 | 27 | 55 | 48 | 33 | 21 |
| 332000.0500 | BT40 | 32 | 60 | 58 | 38 | 24 |
| 332000.0600 | BT40 | 40 | 60 | 70 | 41 | 27 |
332000 Toolholder DIEBOLD
MAS BT, form A, balanced for 8000 rpm
DIN 6358, short version.
Application: For shell end mill and cutting insert mill cutter.
Appropriate accessories:
339610 Cutter spindle key
339720 Cone cleaner
Scope of delivery: With taper key, cutter tightening screw and lathe dog ring
