| Mã đặt hàng | 122410.0100 | 122410.0200 | |
| Kiểu | KM4T | M2T | |
| Dải đo | mm | 3 | 10 |
| Độ phân giải | mm | 0.01 | 0.01 |
| Bezel Ø | mm | 40 | 58 |
| Áp lực đo | N | 0.3...1.5 | 0.3...1.5 |
| 1 revolution | mm | 0.5 | 1 |
| Độ chính xác | µm | 10 | 15 |
| Lettering | 0...50 | 0...100 |
122410 - Dial gauge Käfer
With magnet on the back. Rotatable bezel with tolerance markers. Spindle and thrust stem made of stainless steel..
Designs:
Type KM 4 T: Adhesive strength [N] 120
Type M 2 T: Adhesive strength [N] 220
Package contents:
Delivered in transport packaging.
Appropriate accessories:
Measuring inserts 124008; 124010
