| Mã đặt hàng | 124210.0100 | 124210.0200 | |
| Dải đo | mm | 0.8 | 0.5 |
| Độ phân giải | mm | 0.001 | 0.001 |
| Repeatability | µm | 3 | 3 |
| Độ chính xác | µm | 10 | 10 |
| Probe | mm | 12.5 | 36.5 |
| Tiêu chuẩn chống nước | IP65 | IP65 | |
| Chiều cao số | mm | 6 | 6 |
124210 - Dial test indicator digital SYLVAC S_DIAL S234
Swiss Made - 3-year guarantee. Housing made of polyamide, outside Ø 44 mm. Exchangeabletouch probe with Ø 2 mm carbide ball, swivelling through 270°. Operation via signal line Power USB / RS-232 enables operation without battery.
Features:
LCD display can be rotated 360°
Analog scale
Setting display to zero
Conversion mm/inch
MAX / MIN / DELTA function
Optional feature Analog display
Automatic deactivation
Data output Power
Package contents:
Delivered in transport packaging incl. clamping shaft Ø 8 mm.
Appropriate batteries:
1 pieces 155050.1400 - CR2032 / 3.0 V (included in scope of delivery).
Appropriate accessories:
Signal lines 121540 /.0800 /.2000
Measuring inserts 124250
