Mã đặt hàng | 121533.0100 | 121533.0200 | 121533.1000 | 121533.1100 | |
Kiểu | S | P | S | S | |
Dải đo | mm | 5 | 5 | 5 | 5 |
Độ phân giải | mm | 0.001 | 0.001 | 0.01 | 0.001 |
Áp lực đo | N | 0.50...0.65 | 0.60...1.20 | 0.50...0.65 | 0.50...0.65 |
Độ chính xác | µm | 4 | 4 | 10 | 5 |
Tiêu chuẩn chống nước | IP65 | IP65 | IP65 | IP65 | |
Chiều cao số | mm | 6 | 6 | 6 | 6 |
121533 - Dial gauge digital SYLVAC S233
Swiss Made - 3-year guarantee.Housing made of polyamide, external Ø 44 mm, measuringspindle made of stainless steel, hardened and ground. Mounted with shaft Ø 8-h6 and with dovetail, exchangeable probe tips M2.5. Operation via signal line Power USB / RS-232 enables operationwithout battery.
Designs:
Type P: With protective bellows
Type S: Standard
Features 121533 /.0100 /.0200:
LCD display with analog scale
Setting display to zero
Conversion mm/inch
Change of resolution
MIN/MAX/DELTA function
Data output Power
Features 121533 /.1000 /.1100:
LCD display vertical 90°
Setting display to zero
Conversion mm/inch
Relative / absolute measuring mode
PRESET (fied value setting)
Reverse measuring direction
Data output Power
Package contents:
Delivered in transport packaging, dial indicators with resolution 0.001 mm incl. factory certifiate.
Appropriate batteries:
1 pieces 155050.1400 - CR2032 / 3.0 V (included in scope of delivery).
Appropriate accessories:
Signal lines 121540 /.0800 /.2000
Measuring inserts 124008; 124010
