| Mã đặt hàng | Dải đo | Độ phân giải | Áp lực đo | Độ chính xác | Tiêu chuẩn | Chiều cao số |
| mm | mm | N | µm |
mm | ||
121980.0100 |
12.7 |
0.001 |
≤2.0 | 3 | IP54 | 8.5 |
121980 - Digital dial gauge MITUTOYO SIGNAL - ID-C
Series 543 - Multifunctional dial indicator with absolute scale. Optimal measuring precision even athigh process speeds. 12-24 V DC voltage supply. With open collector connection for external tolerance judgement.
Features:
LCD display
ABSOLUTE™ system
ZERO / ABS function
Tolerance judgment GO/±NG
PRESET (fied value setting)
MAX / MIN / DELTA function
Tolerance judgment by LED
Counting sense reversal
Data output Digimatic
Package contents:
Delivered in transport packaging incl. Signal line 4 m
Appropriate accessories:
Measuring inserts 124008; 124010
Accessories 122000
