Features
- It is small and lightweight, making it extremely easy to use.
- Specially designed for carbide rotary bars, it boasts outstanding chuck precision thanks to its ultra-high precision chuck.
- This is a grinder for carbide rotary burrs that has excellent core runout accuracy in the collet area.
Applications
- For finishing molds, deburring, and chamfering.
Specifications in detail
Air pressure used: 0.4 to 0.6 MPa
Tool tip: Shaft diameter 6 mm (rotary bar)
Exhaust direction: forward
Carbide rotary bar type
Chuck inner diameter (mm): 6
No-load rotation speed (min (-1)): 33000
Air consumption ((m3)/min): 0.18
Hose attachment port: Rc1/4
Exhaust: forward
Total length (mm): 209
No-load rotation speed (rpm): 33000
YOKOTA MG-0CS
