Features
- The attached tube rotates at 20 times per second to generate shock waves.
- The hammering effect of the shock waves instantly removes moisture and dust that has accumulated in recesses.
- The nozzle diameter is 40φ, so a wide area can be treated at once, significantly reducing work time.
- The operating pressure is 0.45MPa or less, which also helps save on electricity bills.
- Durability is approximately 3000 hours.
- The effective range of air is four times that of a regular air gun, at 40% to 60% of the operating pressure. By shortening the working time and reducing the air power consumption, electricity bills are expected to be 1/3 or less compared to conventional products.
Applications
- For cleaning various filter media.
- For draining latticed or uneven surfaces.
- For removing light burrs and polishing powder from processed parts.
- For draining oil, water, and removing excess rust inhibitors from processed parts.
- For cleaning radiator and heat exchanger aluminum fins.
- For stirring and drying granular resin materials.
- For removing dust from work clothes and uniforms.
- For removing dust from semiconductor transport trays and mounting boards.
- For removing dust from food lines and packaging materials.
Specifications in detail
Air gun output: 0.4-0.45MPa
Direct connection with fixed piping Output: 0.3-0.35MPa
Connection port: 1/8 (L10mm) External thread
Injection port diameter: 40φ
Nozzle section total length: 118mm
Air attachment port: G1/8
Total length (mm): 118
Operating temperature (℃): 10-40
Operating air pressure (MPa): 0.4-0.45
Fluid: Air, inert gas
Exhaust outer diameter (mm): 40
Air consumption ((liters)/min): 100-110
Flow rate (NL/min): 100-110
TOHATSU SPG-40
