| Mã đặt hàng | d1 | l2 | l1 | Mã đặt hàng | d1 | l2 | l1 | Mã đặt hàng | d1 | l2 | l1 | Mã đặt hàng | d1 | l2 | l1 |
| mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | ||||
| 254140.0100 | 0.5 | 6 | 22 | 254140.200 | 2.4 | 30 | 57 | 254140.3900 | 4.3 | 47 | 80 | 254140.5800 | 6.8 | 69 | 109 |
| 254140.0200 | 0.6 | 7 | 24 | 254140.210 | 2.5 | 30 | 57 | 254140.4000 | 4.4 | 47 | 80 | 254140.5900 | 7 | 69 | 109 |
| 254140.0300 | 0.7 | 9 | 28 | 254140.220 | 2.6 | 30 | 57 | 254140.4100 | 4.5 | 47 | 80 | 254140.6000 | 7.5 | 69 | 109 |
| 254140.0400 | 0.8 | 10 | 30 | 254140.230 | 2.7 | 33 | 61 | 254140.4200 | 4.6 | 47 | 80 | 254140.6100 | 7.8 | 75 | 117 |
| 254140.0500 | 0.9 | 11 | 32 | 254140.240 | 2.8 | 33 | 61 | 254140.4300 | 4.7 | 47 | 80 | 254140.6200 | 8 | 75 | 117 |
| 254140.0600 | 1 | 12 | 34 | 254140.250 | 2.9 | 33 | 61 | 254140.4400 | 4.8 | 52 | 86 | 254140.6300 | 8.5 | 75 | 117 |
| 254140.0700 | 1.1 | 14 | 36 | 254140.260 | 3 | 33 | 61 | 254140.4500 | 4.9 | 52 | 86 | 254140.6400 | 8.8 | 81 | 125 |
| 254140.0800 | 1.2 | 16 | 38 | 254140.270 | 3.1 | 36 | 65 | 254140.4600 | 5 | 52 | 86 | 254140.6500 | 9 | 81 | 125 |
| 254140.0900 | 1.3 | 16 | 38 | 254140.280 | 3.2 | 36 | 65 | 254140.4700 | 5.1 | 52 | 86 | 254140.6600 | 9.5 | 81 | 125 |
| 254140.1000 | 1.4 | 18 | 40 | 254140.290 | 3.3 | 36 | 65 | 254140.4800 | 5.2 | 52 | 86 | 254140.6700 | 9.8 | 87 | 133 |
| 254140.1100 | 1.5 | 18 | 40 | 254140.300 | 3.4 | 39 | 70 | 254140.4900 | 5.3 | 52 | 86 | 254140.6800 | 10 | 87 | 133 |
| 254140.1200 | 1.6 | 20 | 43 | 254140.310 | 3.5 | 39 | 70 | 254140.5000 | 5.4 | 57 | 93 | 254140.6900 | 10.2 | 87 | 133 |
| 254140.1300 | 1.7 | 20 | 43 | 254140.320 | 3.6 | 39 | 70 | 254140.5100 | 5.5 | 57 | 93 | 254140.7000 | 10.5 | 87 | 133 |
| 254140.1400 | 1.8 | 22 | 46 | 254140.330 | 3.7 | 39 | 70 | 254140.5200 | 5.6 | 57 | 93 | 254140.7100 | 11 | 94 | 142 |
| 254140.1500 | 1.9 | 22 | 46 | 254140.340 | 3.8 | 43 | 75 | 254140.5300 | 5.7 | 57 | 93 | 254140.7200 | 11.5 | 94 | 142 |
| 254140.1600 | 2 | 24 | 49 | 254140.350 | 3.9 | 43 | 75 | 254140.5400 | 5.8 | 57 | 93 | 254140.7300 | 12 | 101 | 151 |
| 254140.1700 | 2.1 | 24 | 49 | 254140.360 | 4 | 43 | 75 | 254140.5500 | 5.9 | 57 | 93 | 254140.7400 | 12.5 | 101 | 151 |
| 254140.1800 | 2.2 | 27 | 53 | 254140.370 | 4.1 | 43 | 75 | 254140.5600 | 6 | 57 | 93 | 254140.7500 | 13 | 101 | 151 |
| 254140.1900 | 2.3 | 27 | 53 | 254140.380 | 4.2 | 43 | 75 | 254140.5700 | 6.5 | 63 | 101 |
| Mã đặt hàng | d1 | l2 | l1 | Mã đặt hàng | d1 | l2 | l1 | Mã đặt hàng | d1 | l2 | l1 | Mã đặt hàng | d1 | l2 | l1 |
| mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | ||||
| 254140.0100 | 0.5 | 6 | 22 | 254140.200 | 2.4 | 30 | 57 | 254140.3900 | 4.3 | 47 | 80 | 254140.5800 | 6.8 | 69 | 109 |
| 254140.0200 | 0.6 | 7 | 24 | 254140.210 | 2.5 | 30 | 57 | 254140.4000 | 4.4 | 47 | 80 | 254140.5900 | 7 | 69 | 109 |
| 254140.0300 | 0.7 | 9 | 28 | 254140.220 | 2.6 | 30 | 57 | 254140.4100 | 4.5 | 47 | 80 | 254140.6000 | 7.5 | 69 | 109 |
| 254140.0400 | 0.8 | 10 | 30 | 254140.230 | 2.7 | 33 | 61 | 254140.4200 | 4.6 | 47 | 80 | 254140.6100 | 7.8 | 75 | 117 |
| 254140.0500 | 0.9 | 11 | 32 | 254140.240 | 2.8 | 33 | 61 | 254140.4300 | 4.7 | 47 | 80 | 254140.6200 | 8 | 75 | 117 |
| 254140.0600 | 1 | 12 | 34 | 254140.250 | 2.9 | 33 | 61 | 254140.4400 | 4.8 | 52 | 86 | 254140.6300 | 8.5 | 75 | 117 |
| 254140.0700 | 1.1 | 14 | 36 | 254140.260 | 3 | 33 | 61 | 254140.4500 | 4.9 | 52 | 86 | 254140.6400 | 8.8 | 81 | 125 |
| 254140.0800 | 1.2 | 16 | 38 | 254140.270 | 3.1 | 36 | 65 | 254140.4600 | 5 | 52 | 86 | 254140.6500 | 9 | 81 | 125 |
| 254140.0900 | 1.3 | 16 | 38 | 254140.280 | 3.2 | 36 | 65 | 254140.4700 | 5.1 | 52 | 86 | 254140.6600 | 9.5 | 81 | 125 |
| 254140.1000 | 1.4 | 18 | 40 | 254140.290 | 3.3 | 36 | 65 | 254140.4800 | 5.2 | 52 | 86 | 254140.6700 | 9.8 | 87 | 133 |
| 254140.1100 | 1.5 | 18 | 40 | 254140.300 | 3.4 | 39 | 70 | 254140.4900 | 5.3 | 52 | 86 | 254140.6800 | 10 | 87 | 133 |
| 254140.1200 | 1.6 | 20 | 43 | 254140.310 | 3.5 | 39 | 70 | 254140.5000 | 5.4 | 57 | 93 | 254140.6900 | 10.2 | 87 | 133 |
| 254140.1300 | 1.7 | 20 | 43 | 254140.320 | 3.6 | 39 | 70 | 254140.5100 | 5.5 | 57 | 93 | 254140.7000 | 10.5 | 87 | 133 |
| 254140.1400 | 1.8 | 22 | 46 | 254140.330 | 3.7 | 39 | 70 | 254140.5200 | 5.6 | 57 | 93 | 254140.7100 | 11 | 94 | 142 |
| 254140.1500 | 1.9 | 22 | 46 | 254140.340 | 3.8 | 43 | 75 | 254140.5300 | 5.7 | 57 | 93 | 254140.7200 | 11.5 | 94 | 142 |
| 254140.1600 | 2 | 24 | 49 | 254140.350 | 3.9 | 43 | 75 | 254140.5400 | 5.8 | 57 | 93 | 254140.7300 | 12 | 101 | 151 |
| 254140.1700 | 2.1 | 24 | 49 | 254140.360 | 4 | 43 | 75 | 254140.5500 | 5.9 | 57 | 93 | 254140.7400 | 12.5 | 101 | 151 |
| 254140.1800 | 2.2 | 27 | 53 | 254140.370 | 4.1 | 43 | 75 | 254140.5600 | 6 | 57 | 93 | 254140.7500 | 13 | 101 | 151 |
| 254140.1900 | 2.3 | 27 | 53 | 254140.380 | 4.2 | 43 | 75 | 254140.5700 | 6.5 | 63 | 101 |
