Power supply: Single phase 100V
Tank oil volume: 2L
Comes with 2m hose (mounting coupler diameter: 3/8)
Compatible tools: Crimp terminal tool-No. 12A, No. 12H, compression terminal tool-No. 16B, EP-520C, EP-1000A
JIS9711 compliant product
Power cord length: 3m
Remote control cord length: 3m
Width x Depth x Height: 306 x 205 x 393 mm
Resin body
Hose can be replaced up to 10m long by separate order.
Set pressure (MPa) High pressure: 68.5
Set pressure (MPa) Low pressure: 2
Discharge volume (L/min) High pressure: 0.3
Discharge volume (L/min) low pressure: 2.9
Power supply (V): Single phase 100
Power cord length (m): 3
Tank capacity(L): 2
Width(mm):306
Depth (mm): 205
Height (mm): 393
Material Oil tank, cover: Resin
Mass and mass units 14kg
Power supply: Single phase 100V
Tank oil volume: 2L
Comes with 2m hose (mounting coupler diameter: 3/8)
Compatible tools: Crimp terminal tool-No. 12A, No. 12H, compression terminal tool-No. 16B, EP-520C, EP-1000A
JIS9711 compliant product
Power cord length: 3m
Remote control cord length: 3m
Width x Depth x Height: 306 x 205 x 393 mm
Resin body
Hose can be replaced up to 10m long by separate order.
Set pressure (MPa) High pressure: 68.5
Set pressure (MPa) Low pressure: 2
Discharge volume (L/min) High pressure: 0.3
Discharge volume (L/min) low pressure: 2.9
Power supply (V): Single phase 100
Power cord length (m): 3
Tank capacity(L): 2
Width(mm):306
Depth (mm): 205
Height (mm): 393
Material Oil tank, cover: Resin
Mass and mass units 14kg
