Thông tin sản phẩm

Minimum display amount 0.01mm
Manufacturer code: 171183
Measurement range (mm): 35-600 (upper row), 25-600 (lower row)
Minimum display (mm): 0.01
Jaw size (mm): 70
Compatible hole diameter (mm): 3-29
Depth bar: No
Instrument error (mm): ±0.05
Power supply: 1 button-type silver oxide battery (SR44)
Power supply (V): 1 button-type silver oxide battery (SR44)
Measurement range (pitch upper row) (mm): 35-600
Measurement range (pitch lower row) (mm): 25-600
Minimum hole diameter (φ): 3
Maximum hole diameter (φ): 29

KANON E-RM2-60B

KANON Việt Nam | Kanon Digital Offset Round Hole Pitch Caliper E-RM2-60B MW1612072

Thương hiệu: KANON
Còn hàng
Liên hệ

MADE IN JAPAN

Features

  • With just one tool, you can measure the pitch between holes and the pitch from the end face to the hole.
  • The conical measuring probe on the main scale side moves up and down, making it possible to measure the pitch of holes with different...
Xem thêm

Thông tin sản phẩm

Minimum display amount 0.01mm
Manufacturer code: 171183
Measurement range (mm): 35-600 (upper row), 25-600 (lower row)
Minimum display (mm): 0.01
Jaw size (mm): 70
Compatible hole diameter (mm): 3-29
Depth bar: No
Instrument error (mm): ±0.05
Power supply: 1 button-type silver oxide battery (SR44)
Power supply (V): 1 button-type silver oxide battery (SR44)
Measurement range (pitch upper row) (mm): 35-600
Measurement range (pitch lower row) (mm): 25-600
Minimum hole diameter (φ): 3
Maximum hole diameter (φ): 29

KANON E-RM2-60B
