Features
- It is a safe, secure and reliable design that is certified to the new JIS standard.
- This is a convenient 4-range model in one unit.
- It is equipped with a live wire warning red LED to notify of the presence of dangerous voltage.
- A test lead (L9787) with a tip length of 35 mm is included.
Applications
- For measuring insulation resistance.
- For electrical construction work.
- For building maintenance and facility construction.
- For inspection and maintenance work.
- For communication equipment and instrumentation equipment (new construction and regular inspections).
- For design work.
Specifications in detail
Compliance standards: JIS C 1302 certified, EN61010 (safety), EN61326 (EMC)
Measurement range (V): 50/125/250/500
Functions: backlight, drop proof, battery voltage check, live wire warning, discharge function, auto power save (APS), battery over-discharge prevention function
Rated measurement voltage (V/MΩ): 50/100, 125/100, 250/100, 500/100
Minimum display (MΩ): 0.01
AC voltage (V): 600
DC voltage (V): -
Width (mm): 152
Depth (mm): 42
Height (mm): 92
Power supply (V): 4 AA alkaline batteries (LR6) (included)
HIOKI IR4041-10
