- PID control ensures that the measured temperature quickly approaches the set temperature, regardless of disturbances such as changes in the amount of solder or the ambient temperature, or changes in the temperature setting, and ultimately results in almost no deviation.
- The digital display shows the set temperature and measured temperature simultaneously.
- The solder bath and heater are separate, making it easy to replace the heater.
Specifications in detail
Solder bath: SUS316
With upper and lower limit warning lamps
With earth wire connection terminal
Power supply (V): AC100
Power consumption (W): 440
Tank dimensions (mm) Width: 91
Body dimensions (mm) Depth: 220
Body dimensions (mm) Height: 124
Tank dimensions (mm) width x depth x height: 91 x 135 x 60
GOOT POT-100C
