Features
- This is a hot wire method that is convenient for measuring minute air speeds.
- It uses an extendable sensor probe (250 to 950 mm), which is convenient for measuring at high altitudes.
- It has a MAX (maximum value)/MIN (minimum value) display for measurement values and a data hold function.
- Comes with display hold function.
- Comes with auto power off function.
- Wind speed is displayed in m/s or km/h.
- It is also possible to measure air volume and temperature using various thermocouples (K/J type, sensors sold separately).
Applications
- For measuring wind speed at various work sites, research institutes, and manufacturing facilities.
Specifications in detail
Sensor: Wind speed sensor: Hot wire, Temperature sensor: Thermistor
Power supply: 6 AA batteries (sold separately) or AC adapter (sold separately)
Width x Depth x Height: 68 x 45 x 177 mm
Operating temperature and humidity: 0 to +50°C, 85% RH or less (but no condensation)
Storage temperature and humidity: -20 to +60°C, 85% RH or less (but no condensation)
Dimensions: Main unit: Approx. W68 x H177 x D45 mm Extendable type Wind speed sensor: [Sensor part] Approx. φ12 x 250-950 mm, [Cable length] Approx. 1.2-1.9 m
Battery life: Normal measurement: Approx. 35 hours (wind speed (When measuring, backlight off, alkaline batteries used)
Accessories: Instruction manual, sensor probe, storage
caseOptions: AC adapter: VSM-932EK, K-type thermocouple sensor: LK model productsMeasuring
air speed range (m/s): 0.20 to 25.0Resolution
(m/s): 0.01/0.1Measuring
accuracy (m/s): ±(5%rdg+0.1m/s) or ±(1%fs+0.1m/s), whichever is greaterMeasuring
air volume range ((M3)/h): 0 to 45000Width
(mm): 68Depth
(mm): 45Height
(mm): 177Power
supply (V): 6 x AA batteries or AC adapter (sold separately)
Power supply: 6 AA batteries or AC adapter (sold separately)
Air speed measurement accuracy: ±(5%rdg+0.1m/s) or ±(1%FS+0.1m/s), whichever is greater
Measurement temperature range (℃): -20 to +50
Measurement range (m/s): 0.20 to 25.0
CUSTOM WS-06
