| Mã đặt hàng | Type | Dải cân lực | Độ phân giải | Đầu vặn |
| N.m | N.m | inch | ||
| 431420.0100 | ADS 4 | 0.8...4 | 0.1 | 1/4“ |
| 431420.0200 | ADS 8 | 1.6...8 | 0.25 | 1/4“ |
| 431420.0300 | ADS 12D | 2.4...12 | 0.5 | 1/4“ |
| 431420.0400 | ADS 25 | 3...25 | 1 | 3/8“ |
| 431420.0500 | ADS 40 | 8...40 | 1 | 3/8“ |
| 431420.0600 | BDS 80AS | 16...80 | 2 | 3/8“ |
| 431420.0700 | BDS 160S | 32...160 | 2.5 | 1/2“ |
| 431420.0800 | BDS 200S | 40...200 | 5 | 1/2“ |
| 431420.0900 | CDS 400S | 80...400 | 10 | 3/4“ |
| 431420.1000 | DDS 800S | 160...800 | 20 | 3/4“ |
| 431420.1100 | EDS 1400 | 280...1400 | 25 | 1“ |
| 431420.1200 | EDS 2000 | 400...2000 | 50 | 1“ |
Measuring and signalling torque wrench with dial gauge and multi-functional friction pointer for controlled fastening and checking of tension on existing fastenings, with dual scale in Nm and lbf-in/lbf-ft on two-tone, easily legible dial faces. With double square drive with ball locking and
integrated ratchet function for clockwise and anti-clockwise tightening (except EDS models). Built in overload protection - mechanical stop up to 25% overload of max. value. Display is accurate to ± 4% of the displayed value, in accordance with DIN EN ISO 6789, based on national standards.
The enclosure is a light, sturdy specially designed aluminium construction, painted red, with black, wear-resistant rubber handles. Models BDS, CDS and DDS are fitted as standard with an audiovisual signal alerting the operator when the set torque is reached. ADS models are EPA-compliant (EPA = Electrostatic Protected Area), for use in electrostatically sensitive applications. EDS models have a two-part handle for easier storage and transport. Delivered in a sturdy plastic box (except for EDS models), with factory test certificate to DIN EN ISO 6789.
